| Model | AC20B-S | AC20B-L | AC25B-S | AC25B-L | |
| Capacity | kg | 2000 | 2500 | ||
| Min. Fork Height | mm | 85 | 75 | 85 | 75 |
| Max. Fork Height | mm | 200 | 190 | 200 | 190 |
| Steering Wheel | mm | Dia.180x50 | |||
| Load Roller Single | mm | Dia.80x93 | Dia.74x93 | Dia.80x93 | Dia.74x93 |
| Load Roller Tandem | mm | Dia.80x70 | Dia.70x70 | Dia.80x70 | Dia.70x70 |
| Size of Fork | mm | 160x48 | |||
| Width overall Forks | mm | 540 | 685 | 540 | 685 |
| Fork Length | mm | 1150 | 1220 | 1150 | 1220 |
| Special fork length available: 800mm, 900mm, 1000mm, 1100mm. |
